Specifications
Product features and specifications subject to change.
Adjustments
User Adjustment Range
9-position hip pad
Seat Adjustment
Fixed seat
Color-coded Pivots & Points of Adjustment
Yes
Frame & Cables
Frame Color
Matte Black
Frame Finish
Proprietary two-coat powder process
Machine Anchoring
Yes
Cable Transmission
Internally lubricated cables and fittings
Optional Kit
Rep Counter (V-KEY-SL-RC1)
Electronic counter displays reps and time with reset buttons
Incremental Weight System (V-KEY-SL-IW)
2.3 kg / 5 lbs.
Tech Specs
Overall Dimensions
139 x 163 x 155 cm / 54.7” x 64.2” x 61”
Max ”In-use” Dimensions
139 x 168 x 155 cm / 54.7” x 66.1” x 61”
Product Weight
253.4 kg / 558.7 lbs.
User Amenities
Contoured Seat
Yes
Instructional Placards
Muscle call outs, start and finish exercise illustrations, proper machine movements, QR code link to how-to videos
Upholstery
Polyurethane molded foam
Personal Storage
Tactile storage mats, personal device cradle
Weight Stack
Total Stack Weight
73 kg / 160 lbs.
Max Training Weight
75.3 kg / 165 lbs. including incremental weight
Max Effective Resistance
142 kg / 312 lbs.
Weight Plate Increments
5 kg / 10 lbs.
Weight Stack Guarding
Full front and rear shields
Consistent Stack Height
Yes: 155 cm / 61”
Back-to-back Configurations
Yes
